FAST-45/65-135LS

Application: Water tanks, etc. are used to detect liquid level and consumption.

Installation method: horizontal only, M10 thread.

Test environment: lack of water or full of water

Detection depth: 65~140 mm

Switch material: SUS304 rod and 2×SUS304 balls

DownloadReturn to List
  • Description
  • Specifications
  • Size

FAST-45/65-135LSS-M10

Application: Water tanks, etc. are used to detect liquid level and consumption.

Installation method: horizontal only, M10 thread.

Test environment: lack of water or full of water

Detection depth: 65~140 mm

Switch material: SUS304 rod and 2×SUS304 balls

Country of Origin: China

Application

Water tanks, etc. are used to detect liquid level and consumption.

Manufacture

SHENZHEN FAST SENSOR CO.,LTD.

Installation method

horizontal only

Detection depth

□ L=45/65~140mm

Parameter

□ SS=SUS304stem and 2×SUS304float ball   □ SP=SUS304stem and 2×PP sealing balls   □ S=SUS304 stem and 2×PP foam balls

Electronic Parameter

□ 1=10W,100V,0.5A Black wire   □ 2=10W,100V,0.5A blue&green

Contact Foram

A=Normal Opening

Detect water level point

□1=D1 water shortage alarm □ 2=D2 water full alarm

Induction form

□ V=Ball adjustable surface    □ No V=Ball non-adjustable surface

Thread

only M10

Wire Material

□ W=UL1007#22 Black/Blue（Standard）   □ C3.8=φ3.8Double insulated cable black  □ C4.5=φ4.5Double insulated cable black

Wire Length(mm）

□ 300（Standard）   □ 500   □ 1000   □ others

Terminals and terminal housings

□ 2Y=Domenstic   □ SM=Korea   □ JST=JP   □ Others

Output Signal

ON/OFF，3or 4Wires

Working Temperature℃

-40~+85

Order Information

Eg, FAST-45/80LSS-2A1+2A2-M12-300W-2Y

Brand - 80 mm deep, SUS304 stem and float - 10W, normally open, lower float lacks water, upper float is full of water, ball non-adjustable surface - M10 - 300 mm wire length, #22 wire - domestic terminal
